UR50Z07 F0S2S BK1 E2ZA短電纜安裝插座Fischer Connectors
發布時間：2024-05-29 09:52:31 瀏覽：695
UR50Z07 F0S2S BK1 E2ZA 是 Fischer Connectors的一款短電纜安裝插座，屬于 UltiMate
系列，尺寸為7。該插座具有以下特點：
設計：2個觸點，插插連接器類型，焊接端接，專為電纜安裝設計。
性能：適用于低壓信號/電源傳輸，具有 IP68 防水密封等級。
材料： 鋁制外殼，無煙煤亞光顏色，高品質絕緣材料。
應用：適用于惡劣環境，如工業、航空、軍事和海洋領域。
該插座以其耐用性和防水性能而著稱，適合在各種嚴苛環境中提供可靠的信號和電源連接。如需詳細數據表，可點擊圖片中的下載按鈕獲取。
其他相關短電纜安裝插座型號：
| 型號 | Contacts | Termination type | Locking system | Signal / Power | Sealing level |
UR50Z07 FOS2S BK1E2ZB
140361 | 2 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 M007S BK1 E2ZB
137809 | 7 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 M010S BK1 E2ZB
132342 | 10 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F004S BK1 E2ZB
125944 | 4 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z11 F019S BK1E1ZB
131568 | 19 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 F009S BK1E1ZB
125680 | 9 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 F004C BK1 E1ZB
122250 | 4 | Crimp | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F002S BK1E2ZB
133790 | 2 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z13 F303S BK1 E1ZB
131485 | 6 | Solder | Plug
dependent | Low Voltage | IP50 |
UR50Z08 F002S BK1E1ZB
133391 | 2 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F009S BK1 E2ZB
124548 | 9 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F005C BK1E2ZB
134743 | 5 | Crimp | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z11 F008S BK1 E1ZB
121325 | 8 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 F005S BK1E1ZB
120221 | 5 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z11 F012S BK1E1ZB
119676 | 12 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F005S BK1E2ZB
129612 | 5 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 F007S BK1 E1ZB
119673 | 7 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F010S BK1E2ZB
125679 | 10 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 F004S BK1E1ZB
119704 | 4 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F007S BK1E2ZB
126488 | 7 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F003S BK1 E2ZB
127712 | 3 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z11 M012S BK1E1ZB
129981 | 12 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 F004C BK1E2ZB
130209 | 4 | Crimp | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z13 F203S BK1 E1ZB
131479 | 5 | Solder | Plug
dependent | Low Voltage | IP50 |
UR50Z11 F016S BK1 E1ZB
128520 | 16 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 M005S BK1E1ZB
129983 | 5 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 M005C BK1 E2ZB
130212 | 5 | Crimp | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z08 M009S BK1E1ZB
137701 | 9 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z07 M009S BK1E2ZB
131027 | 9 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
UR50Z13 F027S BK1 E1ZB
131521 | 27 | Solder | Plug
dependent | Low Voltage | IP68 Mated |
